- Forward Rail Design for smooth precise cutting
- Expandable sub-table for improved stability when cutting long material
- Shadow line projects cut line onto work material
- Dual zone dust extraction ports supress dust scattering of wood chips
- Compatible with AWS* for wireless connectivity with compatible dust extraction
Included accessories
Efficut Saw Blade (E-06993), Dust Bag, Triangular Rule (762001-3), Vertical Vise, Hex Wrench and (191U61-8) Sub base assembly
Optional accessories
Horizontal Vise (122567-9)
Specifications
| Blade diameter | 216mm (8-½") |
| Max cutting capacity | |
| - at 90° | 70 x 312mm |
| - at 45° | 50 x 220mm |
| - at | 30 x 220mm |
| Bevel angle | 48° |
| No load speed | 4,800rpm |
| Overall dimensions | 702 x 551 x 557mm |
| Net weight | 16.4kg |
| Sound Level | 100dB(A) |
| Continuous rating input | 1,000W |
| Voltage | 40V |
| XGT battery compatibility | 2Ah 2.5Ah 4Ah 5Ah |
