FEATURES
- The world's first 18V 5 kg SDS-Max hammer for maximum versatility and portability with equal performance to an AC tool
- Brushless POWERSTATE™ motor provides corded drilling performance
- REDLINK PLUS™ intelligence system delivers an advanced digital overload protection for tool and battery and uniquely enhances the tool performance under load
- HIGH DEMAND™ 9.0 Ah REDLITHIUM™ battery pack delivers up to 5x more run time, up to 35% more power, up to 2x more battery life and operates better down to -20°C than other lithium-ion technologies
- Robust magnesium gear housing for tough environments, exact seat fitting of gear components and better cooling
- Roto-stop and multi position chisel function gives 12 different positions to optimise working angle and end-user ergonomics
- Low 10.6 m/s² vibration construction which enhances usage time per day
- Safety clutch protects operator and machine if drill bit jams
- Flexible battery system: works with all MILWAUKEE® M18™ batteries
| Battery pack capacity (Ah) | 9.0 | ||
|---|---|---|---|
| Battery type | Li-ion | ||
| Blow energy (EPTA)(J) | 6.1 | ||
| Full load hammer action (bpm) | 0 – 3000 | ||
| Kit included | 2 x M18 B9 Battery packs, M12-18 FC Charger, Kitbox | ||
| Max. drilling concrete (mm) | 40 | ||
| Max. drilling core bit (mm) | 100 | ||
| Max. drilling tunnel bit (mm) | 65 | ||
| No load speed (rpm) | 0 – 450 | ||
| No. of batteries supplied | 2 | ||
| Optimised drilling capacity in concrete (mm) | ø 16 – 32 | ||
| Standard equipment | Side handle | ||
| Supplied in | Kitbox | ||
| Tool reception | SDS-Max | ||
| Vibration chiseling (m/s²) | 9.6 | ||
| Vibration drilling (m/s²) | 10.6 | ||
| Voltage (V) | 18 | ||
| Weight with battery pack (kg) | 6.6 |
